Question

다음 그림에 나타는 보드 선도에 대한 H(j\omega)로 알맞은 것은?

Accepted Answer

H(j\omega)=100\dfrac{(1+\dfrac{j\omega}{4})(1+\dfrac{j\omega}{11})}{(1+\dfrac{j\omega}{7})(1+\dfrac{j\omega}{9})}

Answer

H(j\omega)=100\dfrac{(1+\dfrac{j\omega}{7})(1+\dfrac{j\omega}{9})}{(1+\dfrac{j\omega}{4})(1+\dfrac{j\omega}{11})}

Answer

H(j\omega)=100\dfrac{(1+\dfrac{j\omega}{9})(1+\dfrac{j\omega}{11})}{(1+\dfrac{j\omega}{4})(1+\dfrac{j\omega}{7})}

Answer

H(j\omega)=100\dfrac{(1+\dfrac{j\omega}{4})(1+\dfrac{j\omega}{9})}{(1+\dfrac{j\omega}{7})(1+\dfrac{j\omega}{11})}

Answer

H(j\omega)=100\dfrac{(1+\dfrac{j\omega}{4})(1+\dfrac{j\omega}{7})}{(1+\dfrac{j\omega}{9})(1+\dfrac{j\omega}{11})}
